Cambridge Sound Management
Qt X 300 for up to 36,000 ft² - 3 Zone Controller
Qt X 300 for up to 36,000 ft² - 3 Zone Controller
Couldn't load pickup availability
The Qt X 300® is ideal for medium multi-zone spaces of up to 36,000 square feet (3,345 m2). This system is capable of covering up to 3 diverse areas in buildings needing improved speech privacy. This robust and feature-rich system is easy to control and maintain. Users can adjust system settings via the easy-interface front panel. Additionally, the Qt X 300® is an integrated solution offering sound masking along with paging and music via the two auxiliary audio inputs.
Maximum Coverage Area: 36,000 ft² / 3,345 m²
Maximum # of Emitters: 360
Zones: 3
Dimensions: 11" x 3.5" x 3.8" (34.9 cm x 8.9 cm x 9.7 cm)
Weight: 1.5 lbs (.68 kg)
FEATURES:
Mounting Style: Wall or equipment rack
Password: Yes- 2 levels
Panel Lock: Yes
Internal Clock: Yes
Audio Inputs: 2 (fixed terminal block)
Module Control - Front Panel, LAN, Software (TCP/IP browser based)
Volume Control - by Zone and Sudio Source
Day/Night Levels - Yes, by zone
Day/Night ramping - Yes, by zone
System Monitoring - System Electronics
Email Error Notification - Yes
Safety Alarm Integration - Yes
Banks
Conference Centers
Corporate Office Buildings
Counseling Centers
Courthouses
Financial Firms
Government Offices
Hospitals
Hotels
Houses of Worship
Law Offices
Libraries
Open Offices and Call centers
Research Laboratories
Resorts and Spas
Retail Buildings
SCIFs (Sensitive Compartmented
Information Facilities)
Sleep Centers
-
Qt Emitters™
The backbone of the Qt® sound masking system. These emitters deliver 4 incoherent audio channels making the Qt system the best sound masking system on the market. The standard mounting is for acoustical tile ceilings. -
Universal Bracket
This enclosure is used for mounting the Qt emitter to the wall or ceiling. -
Beam Bracket
This enclosure is used for mounting the Qt emitter to exposed I-beams. -
Drywall Mount
This enclosure is used for mounting the Qt emitter into drywall ceilings. -
Conduit Mount
This enclosure is used for mounting the Qt emitter into ceilings in regions requiring conduit mounting. -
Plenum Back Can
This enclosure is used for mounting the Qt emitter into acoustic ceiling tile in regions with special fire and/or conduit requirements. -
Qt ROOM CONTROL
The Qt Room Control can be used to adjust the sound masking level with 6 discrete level selections (including off) for an individual room or space with 2-8 emitters
EQUIPMENT RACK MOUNT (OPTIONAL)
Users can choose to install the Qt X 300 into an existing equipment rack
Qt EMITTER INSTALLATION
Qt emitters are installed along a simple grid pattern based on ceiling height. For a standard 9’ (2.75 m) ceiling, emitters are laid out on a 10’ x 10’ (3 m x 3m) grid. Emitters can be installed into standard ceiling tiles ranging from 0.5” to 1.5” (1.3 cm – 3.8 cm) thick. Emitters are plug-and-play, daisy-chained together with CAT-3, plenum-rated cables. We supply with every emitter, pre-terminated CAT3 cables with industry standard RJ-45 connectors.
